400 Ton, HERLAN P8 IMPACT EXTRUSION PRESS
Our stock number:
115496
Click on picture below for larger version
Nominal Power Mp: 400
Stroke Length mm: 335
Aluminum - 99.5 :
Max Diameter mm: 65
Wall Thickness mm: 0.12
Max Extruded Length mm: 255
Zinc 130 deg C :
Max Diameter mm: 56
Wall Thickness mm: 0.4
Max extruded Length mm: 154
Max Diameter Soft Metal mm: 65
Number of Strokes per minute spm: 65
Motor Power kW: 22
Size :
Length mm: 3960
Width mm: 2890
Height mm: 1760
Weight kp: 11600
Weight with seaworthy packing : 13200
Outside Dimensions of Seaworhty Crating :
Length mm: 4220
Width mm: 2400
Height mm: 2120
Includes
Bowl Feeder
Air Actuated Clutch
Motor
Ejector
