630MM RWF 4HI REVERSING COLD ROLLING MILL   Our stock number: 111677

630MM RWF 4HI REVERSING COLD ROLLING MILL

Click on picture below for larger version
630MM RWF 4HI REVERSING COLD ROLLING MILL630MM RWF 4HI REVERSING COLD ROLLING MILL630MM RWF 4HI REVERSING COLD ROLLING MILL630MM RWF 4HI REVERSING COLD ROLLING MILL
630MM RWF 4HI REVERSING COLD ROLLING MILL630MM RWF 4HI REVERSING COLD ROLLING MILL630MM RWF 4HI REVERSING COLD ROLLING MILL630MM RWF 4HI REVERSING COLD ROLLING MILL


Material- Carbon Steel
Material Thickness max/min - 6.5mm/0.20mm

Entry Uncoiler, Snubber Roll, Straightener
Coil Weight - 7 ton
Coil outside diameter, max - 1400 mm
Coil inside diameter - 508 mm

Max material width - 630 mm
Material Thickness max/min- 6.0 mm/ 0.40 mm

Roll Face- 680mm
Max Speed- 300 m/min
Separation Force- 600 ton
Tension at Coiler - 8 ton

Back up roll Dimensions- 550mm x 680mm face, 7 available (used)
Work Roll Dimensions -250mm X 680mm face
73 available (new)
45 available (used)

Mill Motors - 400 KW, 380 VOLT, DC , (2)
Back up roll driven
Hydraulic screws, bottom

Winder Motors - Outboard Supports
220 KW, 380 VOLT, DC (2) EA,

X-ray, AM 241
AGC, 1970
Conventional controls
Siemens PLC
Motor Generator
(1) 904kw, (2) 510 kw, MOTORS, 800 VOLT
(1) 1400 kw GENERATOR, 5000 VOLTS

Paper Filter system
